Product Description

A: Overview

SW-L350ACDC is the new developed 50L large flow portable particle counter, equipped with 7-inch touch screen.  This equipment has several characteristics: human-machine interaction interface makes operation easy and convenient; the imported air pump can work stably and efficiently with little noise; power supply includes AC power supply and built-in large capacity DC battery.

The advantage of large sampling flow rate helps to detect particles in clean environment more correctly, quickly and efficiently, and is definitely the first choice for pharmacy or electronic industry. Its application field includes:

  1. detection of the cleanroom’s cleanliness
  2. routing inspection for pharmacy or electronic industry
  3. measurement of high concentration aerosol
  4. measurement of airborne particles
  5. test on filter leakage

B: Technical Index

  • sampling flow rate：50L /min（1.77cfm）
  • size channels：0.3, 0.5, 1 ,3, 5, 10μm
  • clean-down capability：≤10min
  • size distribution error：0.5um 5um≤±30%
  • concentration indication error：0.5um≤±30%
  • repeatability relative error：≤±10%
  • cleanliness criteria：ISO14644/ FS209E/ new edition GMP
  • light source：Japanese original laser diode
  • data communication interface：RS232
  • power：AC 220V 50Hz
  • overall size/weight：250*260*320mm / 11Kg
  • working condition：5℃～30℃, 30%-70%RH



C: Basic Function



  • sampling time：self-set (1s～99min)
  • sampling delay：self-set (1s～99s)
  • sampling frequency：1 to 99 or continuous
  • sampling interval：0~999s
  • test mode：single /continuous/delay
  • data storage capacity：3000 sets
  • sampling location number：3000 sets
  • counting mode：accumulative
  • alarm level：Class100～Class300,000(FED209E ) or 5～9 (ISO14464-1)
  • OSD mode：LCD blue large screen
  • print：built-in thermosensitive printer
  • cleanliness standard：GB/T6167-2007 / JJF1190-2008
  • standard accessories：reset filter，isokinetic sampling head，tripod ，portable protection box

Operation instruction,  Calibration report, typing paper

  • optional accessories：data analysis software CD and data line

C:   Basic Function

Sampling time (1s～99min)  self-set
Sampling delay (1s～99min)  self-set
Sampling frequency 1~99 or continuously
sampling interval 0~999s
Test mode single/continuous/delay
data storage capacity 1000 sets
counting mode Accumulative
cleanliness criteria ISO14644、FS209E、 GMP
alert level Class100 ～ Class300,000(FS209E )
Or 5 ～ 9(ISO14464-1)
display LCD blue large screen
Print built-in thermosensitive printer
GB/T6167-2007，JJF1190-2008
standard accessories reset filter，isokinetic sampling head，tripod ，portable protection box, Operation instruction,  Calibration report, printer
optional accessories Built-out temperature and humidity sensor，data analysis software CD and data line
